1. 관련표준
- CISPR 16-1-1 : Radio disturbance and immunity measuring apparatus – Measuring apparatus
- CISPR 16-1-2 : Radio disturbance and immunity measuring apparatus – Coupling devices for conducted disturbance measurements
- CISPR 16-1-3 : Radio disturbance and immunity measuring apparatus – Ancillary equipment – Disturbance power
- CISPR 16-1-4 : Radio disturbance and immunity measuring apparatus – Antennas and test sites for radiated disturbance measurements
- CISPR 11 : Industrial, scientific and medical equipment – Radio-frequency disturbance characteristics – Limits and methods of measurement
- CISPR 32 : Electromagnetic compatibility of multimedia equipment – Emission requirements
- IEC 61000-4-3 : Electromagnetic compatibility (EMC) Part 4-3: Testing and measurement techniques - Radiated, radio-frequency, electromagnetic field immunity test

2. 사양
2.1. 사이즈
- 22m x 12.8m x 9m(H)
2.2. Shield Effectiveness(SE)
- 시험 규격 : IEEE 299
- 주파수 범위 : 14kHz - 18GHz
2.3. Normalized Site Attenuation(NSA)
- 시험 규격 : CISPR 16-1-4
- 주파수 범위 : 30MHz - 1GHz
2.4. Site VSWR(sVSWR)
- 시험 규격 : CISPR 16-1-4
- 주파수 범위 : 1GHz - 18GHz
2.5. Field Uniformity (FU)
- 시험 규격 : IEC 61000-4-3
- 주파수 범위 : 80MHz - 18GHz
2.6. Ambient Noise level
- 시험규격 : CISPR 32
- 주파수 범위 : 10kHz - 18GHz
