o Measurement method : Dynamic(Pulse)
o Time Resolution : 1ms
o Temperature Resolution : 0.1℃
o Available Measurement Channel : Max 8 Channels
o Voltage : More than Max. 50V
o Current : More than Max. 10A
o Temperature Range(Cold Plate) : More than Max. 150℃
o Measuring Plate Size : 150X150mm
o Resistance Range : 0.01K/W ~ 8K/W
o Thickness Range : 0 ~ 5mm
o Thickness Resolution : 25µm
